Internally threaded ball valves are generally smaller, and those with a diameter below DN50 are more common. Because the pipe connected to the valve is difficult to thread, they are generally not suitable for use if they exceed this size. Threaded ball valves are made of different materials and can be applied to a variety of media respectively. They can be used for two-position cutting or adjustment on various pipelines with pressures ranging from PN1.0 to 4.0MPa and operating temperatures from -29 to 300°C. It has the advantages of simple wiring, compact structure, small size, light weight, low resistance, stable and reliable action.

Threaded Ball Valve

- Connection method: threaded buckle
- Nominal diameter: DN15-DN100
- Valve body material: stainless steel 304, stainless steel 316, stainless steel 316L
- Pressure temperature: PN16 low temperature, normal temperature, high temperature
- Structural form: straight-through
- Application areas: ball valve 304 high temperature resistant steam manual ball valve electric stainless steel ball valve switch hot oil regulating valve
